Find the formulation that’s right for your project.
  • All
  • Originals
  • High Rebound
  • Slow Recovery
  • Eco Solutions
  • Thermal
OrthoLite insoles can be fully customized to meet your exact design specifications by combining various formulations, hardnesses, colors, and mold designs to help you deliver a competitive advantage and unique comfort performance story.
  • OrthoLite® HybridPlus-Bio™ expands on our range of eco formulations combining our Hybrid and Bio-oil formulations elevating the total eco content to 57% to further reduce the use of petroleum and get us all closer to the end goal of ZERO waste.
    Product Details
    1 Available Formulation Colors
    View All
    • Mint Green
    Density
    0.14 g/cm3
    Hardness
    24° +/- 4° Asker C
    Thickness
    2mm-20mm
    Sheet Size
  • OrthoLite® HybridPlus-Recycled™ is a result of our expanding commitment to the creation of more sustainable footwear technologies that close the loop on production waste material and get us all closer to the end goal of ZERO waste.
    Product Details
    1 Available Formulation Colors
    View All
    • Mint Green
    Density
    0.12 g/cm3
    Hardness
    25° Asker C
    Thickness
    2mm-20mm
    Sheet Size
  • OrthoLite® insole technology creates a thermal barrier that elevates footwear temperature regulation to an unprecedented level, infusing open-cell PU foam with a proprietary aerogel creating the lightest, most advanced version of the world’s most insulative material delivering unmatched thermal insulation and all-day comfort and cold weather protection underfoot.
    Product Details
    1 Available Formulation Colors
    View All
    • Lava Red
    Density
    0.11g/cm3
    Hardness
    25º+/-4˚ Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 200cm

    Finished Goods: Available in molded and die-cut.
  • OrthoLite® insoles can be customized to meet your exact specifications by combining formulations, densities, colors, and mold designs, giving you a competitive advantage and unique comfort and performance story.
    Product Details
    17 Available Formulation Colors
    View All
    • Air Blue
    • Antique Bronze
    • Apricot Orange
    • Brown Sugar
    • Burnt Sienna
    • Fossil
    • Green
    • Grey
    • Lime Green
    • Neutral Grey
    • Orange Rust
    • Persimmon Orange
    • Red
    • Russet Brown
    • Seedpearl Hybrid
    • Shocking Pink
    • Yellow
    Density
    .11D
    Hardness
    5-10° Asker C
    15º Asker C
    25º Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 200cm
    110cm x 170cm
    110cm x 147cm
  • OrthoLite® raised the bar to new heights with the launch of X40™ that set the industry standard for high-rebound comfort and performance. Now OrthoLite® takes rebound to incredible new heights with even more rebound and energy return.
    Product Details
    2 Available Formulation Colors
    View All
    • Red
    • Seedpearl Hybrid
    Density
    0.16g/cm3
    Hardness
    25°+/-4° Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 147cm
    110cm x 170cm
  • OrthoLite® X40 Series is our range of performance formulations with the highest rebound, that let you dial in the perfect elasticity for your insole application.
    Product Details
    6 Available Formulation Colors
    View All
    • Billiard
    • Castlerock
    • Fossil
    • Red
    • Seedpearl Hybrid
    • True Blue
    Density
    0.16g/cm3
    Hardness
    ​25°+/-4° Asker C
    Thickness
    ​2mm-20mm
    Sheet Size
    ​110cm x 170cm
  • OrthoLite® X35 Series is our range of performance formulations with the highest rebound, that let you dial in the perfect elasticity for your insole application.
    Product Details
    2 Available Formulation Colors
    View All
    • Fossil
    • Seedpearl Hybrid
    Density
    ​0.145g/cm3
    Hardness
    ​25°+/-4° Asker C
    Thickness
    ​2mm-20mm
    Sheet Size
    ​110cm x 200cm
  • OrthoLite® X Series is our range of performance formulations with the highest rebound, that let you dial in the perfect elasticity for your insole application.
    Product Details
    2 Available Formulation Colors
    View All
    • Billiard
    • Seedpearl Hybrid
    Density
    ​0.12g/cm3
    Hardness
    ​20°+/-4° Asker C
    Thickness
    2mm-20mm​
    Sheet Size
    ​110cm x 200cm
  • OrthoLite® Ultra™ is designed to meet the ever-increasing demand for ultra-lightweight comfort in today’s active lifestyle footwear.
    Product Details
    9 Available Formulation Colors
    View All
    • Antique Bronze
    • Burnt Sienna
    • Fossil
    • Green
    • Lemon Chrome
    • Lime Green
    • Red
    • Seedpearl Hybrid
    • Yellow
    Density
    ​0.085g/cm3
    Hardness
    78-90 Asker F
    5-10° +/-4° Asker C
    15° +/-4° Asker C
    25° +/-4° Asker C
    Thickness
    ​2mm-20mm
    Sheet Size
    ​110cm x 147cm
    110cm x 170cm
    110cm x 200cm
  • OrthoLite® X-Sorb™ is the highest density, lowest rebound foam ever engineered by OrthoLite®—providing outstanding shock-dampening and energy absorption. The exclusive formulation is ideal for a wide range of applications across footwear, sports and safety equipment where unequaled comfort, performance, stability and mobility are critical.
    Product Details
    2 Available Formulation Colors
    View All
    • Grey
    • Seedpearl Hybrid
    Density
    0.18D
    Hardness
    15°+/-4° Asker C
    Thickness
    3mm-20mm
    Sheet Size
    110cm x 147cm
    110cm x 170cm
  • OrthoLite® Lazy™ gives a custom fit—quickly molding to the shape of the foot and then instantly rebounding when the foot is removed.
    Product Details
    2 Available Formulation Colors
    View All
    • Seedpearl Hybrid
    • Yellow
    Density
    0.15g/cm3
    Hardness
    75° Asker F
    Thickness
    2mm-12mm
    Sheet Size
    110cm x 170cm
  • OrthoLite® Impressions™ provides immediate step-in comfort and molds for a truly custom fit over time.
    Product Details
    2 Available Formulation Colors
    View All
    • Seedpearl Hybrid
    • Tawny Port
    Density
    0.15g/cm3
    Hardness
    70°-80° Asker F
    Thickness
    2mm-12mm
    Sheet Size
    110cm x 170cm
  • OrthoLite® Imperial™ provides outstanding cushioning even in thin applications—making it the perfect choice for a wide range of uses.
    Product Details
    2 Available Formulation Colors
    View All
    • Blue Grass
    • Seedpearl Hybrid
    Density
    0.22g/cm3
    Hardness
    25°+/-4° Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 100cm
  • OrthoLite® R&R™ delivers exceptional comfort and maximum recovery for athletes of all levels looking to restore and rejuvenate their feet from an active day.
    Product Details
    2 Available Formulation Colors
    View All
    • Castlerock
    • Seedpearl Hybrid
    Density
    0.16g/cm3
    Hardness
    15°+/-4° Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 170cm
  • OrthoLite® Eco™ expands on our popular EcoLT™ formulation—more than doubling the bio-oil content to further reduce the use of petroleum.
    Product Details
    2 Available Formulation Colors
    View All
    • Fairway
    • Seedpearl Hybrid
    Density
    0.13g/cm3
    Hardness
    15°+/-4° Asker C
    25°+/-4° Asker C
    35°+/-4° Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 200cm
  • OrthoLite® Eco LT™ brings innovative eco-upgrades to our original .11D and .13D formulations, replacing a portion of the petroleum with plant-derived bio-oil.
    Product Details
    15 Available Formulation Colors
    View All
    • Air Blue
    • Amazon
    • Brown Sugar
    • Burnt Sienna
    • Fossil
    • Green
    • Grey
    • Lime Green
    • Neutral Grey
    • Orange Rust
    • Persimmon Orange
    • Red
    • Russet Brown
    • Seedpearl Hybrid
    • Shocking Pink
    Density
    .11D
    Hardness
    15º and 25º Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 200cm
    110cm x 170cm
    110cm x 147cm
  • OrthoLite® Hybrid™ is a patent pending formulation that uniquely blends 5% recycled rubber and 15% production waste foam for 20% eco-content for uncompromised performance with less impact on the planet.
    Product Details
    1 Available Formulation Colors
    View All
    • Seedpearl Hybrid
    Density
    0.12 g/cm3
    Hardness
    25° Asker C
    Thickness
    2mm-20mm
    Sheet Size
    110cm x 200cm
    110cm x 170cm
    110cm x 147cm
  • OrthoLite® Recycled™ is a result of our expanding commitment to the creation of more sustainable technologies that close the loop on postproduction waste material and get us closer to the end goal of ZERO waste.
    Product Details
    1 Available Formulation Colors
    View All
    • Mixed
    Density
    0.19-0.27g/cm3
    Hardness
    29°-43°+/-4° Asker C
    Thickness
    ​2mm-20mm
    Sheet Size
